5CPS-S3215M

Magnetic Proximity switch is widely used in automation control, alarm system, output ON/OFF signal depending on the position of equipment.
Order Hotline:
No such product
Inquiry
Description
Packing

Magnetic Proximity Switch Datasheet

Model NO. 5CPS-S3215M
Installation Surface mounting
Pull-in Value 10-13AT
Switching Type NO ( SPST )
Material ZINC-ALLOY
Working Temperature -20~80℃
Wire Gauge 1007 24AWG
Wire Length 300mm
Switching Voltage 200 VDC
Switching Current 0.5A
Contact life >100000 times



1.Magnetic Proximity switch is widely used in automation control, alarm system, output ON/OFF signal depending on the position of equipment.

2.Surface switch can be mounted with screws or double side tape , flush switch can be mounted in hole to keep covert.

3.Switching type definition:
 NO: Normally open, switch ON when magnet nearly.
 NC: Normally close,switch OFF when magnet nearly . [customizable]
 NO&NC: 3 wires output, both with NO&NC.  [customizable]

4.Please do not knock switch when mounting.
